Magnetically coupled centrifugal pumps dry-running safe

centrifugalPUMP - Series M

Features

  • The standard for pumping corrosive liquids
  • Highest efficiency with up to 70% efficiency
  • Extreme dry-running capability
  • Versions according to ATEX 2014/34 / EU



Applications

  • Chemical industry
  • Metal industry
  • Wastewater treatment
  • Electronics industry
  • Mining
  • Pharmacy
Magnetgekuppelte Kreiselpumpe M

Standard versions

M5                                            M11
H (max.): 7 m                                      H (max.): 14 m
Q (max.): 3,5 m3/h                               Q (max.): 20 m3/h

M6H                                                  M22
H (max.): 10 m                                    H (max.): 44 m
Q (max.): 9 m3/h                                 Q (max.): 42 m3/h

M8
H (max.): 14 m
Q (max.): 15 m3/h

Q (max.) at 50Hz

Technical specifications

  • Threaded connection or flange
  • Materials: Polypropylene or PVDF
  • Max. viscosity above 150cP
  • Max. temperature: 82° C (PP) 104° C (PVDF)
